- Fairchild (onsemi)
- 1200 V
- 2.4V @ 15V, 40A
- 600V, 40A, 10Ohm, 15V
- 40ns/475ns
- 2.7mJ (on), 1.1mJ (off)
- TO-247
- -
- 65 ns
- 555 W
- TO-247-3
- Bulk
- -55°C ~ 175°C (TJ)
- Through Hole
- Standard
- Trench Field Stop
- 370 nC
- 160 A
- 80 A
| Product Attribute |  |
 |
 |
 |
|---|---|---|---|---|
| Part Number | FGH40T120SMD | FGH40T120SMD | IRG4PC50KDPBF | FGH40T120SMD |
| Manufacturer | Fairchild Semiconductor | Fairchild Semiconductor | Infineon Technologies | onsemi |
| IGBT Type | Trench Field Stop | Trench Field Stop | - | Trench Field Stop |
| Package | Bulk | Bulk | Tube | Tube |
| Test Condition | 600V, 40A, 10Ohm, 15V | 600V, 40A, 10Ohm, 15V | 480V, 30A, 5Ohm, 15V | 600V, 40A, 10Ohm, 15V |
| Input Type | Standard | Standard | Standard | Standard |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole |
| Series | - | - | - | - |
| Package / Case | TO-247-3 | TO-247-3 | TO-247-3 | TO-247-3 |
| Current - Collector Pulsed (Icm) | 160 A | 160 A | 104 A | 160 A |
| Gate Charge | 370 nC | 370 nC | 200 nC | 370 nC |
| Power - Max | 555 W | 555 W | 200 W | 555 W |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V | 1200 V | 600 V | 1200 V |
| Switching Energy | 2.7mJ (on), 1.1mJ (off) | 2.7mJ (on), 1.1mJ (off) | 1.61mJ (on), 840µJ (off) | 2.7mJ (on), 1.1mJ (off) |
| Vce(on) (Max) @ Vge, Ic | 2.4V @ 15V, 40A | 2.4V @ 15V, 40A | 2.2V @ 15V, 30A | 2.4V @ 15V, 40A |
| Td (on/off) @ 25°C | 40ns/475ns | 40ns/475ns | 63ns/150ns | 40ns/475ns |
| Operating Temperature | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 175°C (TJ) |
| Reverse Recovery Time (trr) | 65 ns | 65 ns | 50 ns | 65 ns |
| Current - Collector (Ic) (Max) | 80 A | 80 A | 52 A | 80 A |
| Supplier Device Package | TO-247 | TO-247 | TO-247AC | TO-247-3 |
