- Panasonic
- 0 V ~ 60 V
- 1.14VDC
- Gull Wing
- 8-SMD
- PhotoMOS™ AQW
- 8-SMD (0.300", 7.62mm)
- Tube
- AC, DC
- 2.5 Ohms
- Surface Mount
- 500 mA
- SPST-NO (1 Form A) x 2
- AQW212
| Product Attribute | |
 |
 |
 |
|---|---|---|---|---|
| Part Number | AQW212EHA | AQW212EHA | CPC1943G | CD4850E1UR |
| Manufacturer | Panasonic Electric Works | Panasonic Electric Works | IXYS Integrated Circuits Division | Sensata-Crydom |
| Base Product Number | AQW212 | AQW212 | CPC1943 | CD4850 |
| Mounting Type | Surface Mount | Surface Mount | Through Hole | Chassis Mount |
| Supplier Device Package | 8-SMD | 8-SMD | 6-DIP | - |
| Voltage - Load | 0 V ~ 60 V | 0 V ~ 60 V | 0 V ~ 400 V | 48 V ~ 660 V |
| Package / Case | 8-SMD (0.300", 7.62mm) | 8-SMD (0.300", 7.62mm) | 6-DIP (0.300', 7.62mm) | Hockey Puck |
| Circuit | SPST-NO (1 Form A) x 2 | SPST-NO (1 Form A) x 2 | SPST-NO (1 Form A) | SPST-NO (1 Form A) x 2 |
| Voltage - Input | 1.14VDC | 1.14VDC | 1.2VDC | 15 ~ 32VDC |
| Output Type | AC, DC | AC, DC | AC, Zero Cross | AC |
| Load Current | 500 mA | 500 mA | 500 mA | 50 A |
| Package | Tube | Tube | Tube | Bulk |
| Series | PhotoMOS™ AQW | PhotoMOS™ AQW | CPC | Evolution Dual |
| Termination Style | Gull Wing | Gull Wing | PC Pin | Screw Terminal |
| On-State Resistance (Max) | 2.5 Ohms | 2.5 Ohms | - | - |
